This page contains two quickstarts to help you get started with the Unstructured user interface (UI).
If you’re not sure which quickstart to use, we recommend starting with the local quickstart.
The local quickstart is a fast and easy way to learn about Unstructured. When you’re happy with the results from the workflow that you create there, it is straightforward to turn it into a production-ready workflow with all of the settings that you want already in place!
This quickstart uses a no-code, point-and-click user interface (UI) in your web browser to have Unstructured process a single file that is stored on your local machine.
The file is first processed on Unstructured-hosted compute resources. The UI then shows the processed data that Unstructured generates for that file.
You can download that processed data as a .json
file to your local machine.
This approach enables rapid, local, run-adjust-repeat prototyping of end-to-end Unstructured ETL+ workflows with a full range of Unstructured features. After you get the results you want, you can then attach remote source and destination connectors to both ends of your existing workflow to begin processing remote files and data at scale in production.
To run this quickstart, you will need a local file with a size of 10 MB or less and one of the following file types:
File type |
---|
.bmp |
.csv |
.doc |
.docx |
.email |
.epub |
.heic |
.html |
.jpg |
.md |
.odt |
.org |
.pdf |
.pot |
.potm |
.ppt |
.pptm |
.pptx |
.rst |
.rtf |
.sgl |
.tiff |
.txt |
.tsv |
.xls |
.xlsx |
.xml |
For processing remote files at scale in production, Unstructured supports many more files types than these. See the list of supported file types.
Unstructured also supports processing files from remote object stores, and data from remote sources in websites, web apps, databases, and vector stores. For more information, see the source connector overview and the remote quickstart for how to set up and run production-ready Unstructured ETL+ workflows at scale.
If you do not have any files available, you can use one of the sample files that Unstructured offers in the UI. Or, you can download one or more sample files from the example-docs folder in the Unstructured repo on GitHub.
Sign up and sign in
Create a workflow
In the Unstructured UI, on the sidebar, click Workflows.
Click New Workflow.
Select Build it Myself, if it is not already selected.
Click Continue. The visual workflow editor appears.
The workflow is represented visually as a series of directed acyclic graph (DAG) nodes. Each node represents a step in the workflow. The workflow proceeds end to end from left to right. By default, the workflow starts with three nodes:
Process a local file
Drag the file that you want Unstructured to process from your local machine’s file browser app and drop it into the Source node’s Drop file to test area. The file must have a size of 10 MB or less and one of the file types listed at the beginning of this quickstart.
If you are not able to drag and drop the file, you can click Drop file to test and then browse to and select the file instead.
Alternatively, you can use a sample file that Unstructured offers. To do this, click the Source node, and then in the Source pane, with Details selected, on the Local file tab, click one of the files under Or use a provided sample file. To view the file’s contents before you select it, click the eyes button next to the file.
Above the Source node, click Test.
Unstructured displays a visual representation of the file and begins processing its contents, sending it through each of the workflow’s nodes in sequence. Depending on the file’s size and the workflow’s complexity, this processing could take several minutes.
After Unstructured has finished its processing, the processed data appears in the Test output pane, as a series of structured elements in JSON format.
In the Test output pane, you can:
.json
file to your local machine by clicking Download full JSON.When you are done, click the Close button in the Test output pane.
Add more nodes to the workflow
You can now add more nodes to the workflow to do further testing of various Unstructured features and with the option of eventually moving the workflow into production. For example, you can:
Add a Chunker node after the Partitioner node, to chunk the partitioned data into smaller pieces for your retrieval augmented generation (RAG) applications. To do this, click the add (+) button to the right of the Partitioner node, and then click Enrich > Chunker. Click the new Chunker node and specify its settings. For help, click the FAQ button in the Chunker node’s pane. Learn more about chunking and chunker settings.
Add an Enrichment node after the Chunker node, to apply enrichments to the chunked data such as image summaries, table summaries, table-to-HTML transforms, and named entity recognition (NER). To do this, click the add (+) button to the right of the Chunker node, and then click Enrich > Enrichment. Click the new Enrichment node and specify its settings. For help, click the FAQ button in the Enrichment node’s pane. Learn more about enrichments and enrichment settings.
Image summary descriptions, table summary descriptions, and table-to-HTML output is generated only when the Partitioner node in a workflow is set to use the High Res partitioning strategy and the workflow also contains an image description, table description, or table-to-HTML enrichment node.
Setting the Partitioner node to use Auto, VLM, or Fast in a workflow that also contains an image description, table description, or table-to-HTML enrichment node will not generate any image summary descriptions, table summary descriptions, or table-to-HTML output, and it could also cause the workflow to stop running or produce unexpected results.
Add an Embedder node after the Enrichment node, to generate vector embeddings for performing vector-based searches. To do this, click the add (+) button to the right of the Enrichment node, and then click Transform > Embedder. Click the new Embedder node and specify its settings. For help, click the FAQ button in the Embedder node’s pane. Learn more about embedding and embedding settings.
Each time you add a node or change its settings, you can click Test above the Source node again to test the current workflow end to end and see the results of the changes, if any.
Keep repeating this step as many times as you want, until you get the results you want.
Next steps
After you get the results you want, you have the option of moving your workflow into production. To do this, complete the following instructions.
The following instructions have you create a new workflow that is suitable for production. This behavior is planned to be fixed in a future release, allowing you to update the workflow that you just created, rather than needing to create a new one.
With your workflow remaining open in the visual workflow editor, open a new tab in your web browser, and in this new tab, sign in to your Unstructured account:
In this new tab, create a source connector for your remote source location. This is the location in production where you have files or data in a file or object store, website, database, or vector store that you want Unstructured to process.
Create a destination connector for your remote destination location. This is the location in production where you want Unstructured to put the processed data as .json
files in a file or object store, or as records in a database or vector store.
Create a workflow: on the sidebar, click Workflows, and then click New Workflow. Select Build it Myself, and then click Continue to open the visual workflow editor.
In the visual workflow editor, click Source.
In the Source pane, with Details selected, on the Connectors tab, select the source connector that you just created.
Click the Destination node.
In the Destination pane, with Details selected, select the destination connector that you just created.
Using your original workflow on the other tab as a guide, add any additional nodes to this new workflow as needed, and configure those new nodes’ settings to match the other ones.
Click Save.
To run the workflow:
a. Make sure to click Save first.
b. Click the Close button next to the workflow’s name in the top navigation bar.
c. On the sidebar, click Workflows.
d. In the list of available workflows, click the Run button for the workflow that you just saved.
e. On the sidebar, click Jobs.
f. In the list of available jobs, click the job that you just ran.
g. After the job status shows Finished, go to the your destination location to see the processed files or data that Unstructured put there.
See also the remote quickstart for more coverage about how to set up and run production-ready Unstructured ETL+ workflows at scale.
This quickstart uses a no-code, point-and-click user interface in your web browser to get all of your data RAG-ready. Data is processed on Unstructured-hosted compute resources.
The requirements are as follows.
Sign up and sign in
Set the source (input) location
Set the destination (output) location
Define the workflow
In the sidebar, click Workflows.
Click New Workflow.
Next to Build it for Me, click Create Workflow.
For Workflow Name, enter some unique name for this workflow.
In the Sources dropdown list, select your source location from Step 3.
In the Destinations dropdown list, select your destination location from Step 4.
Click Continue.
The Reprocess All box applies only to blob storage connectors such as the Amazon S3, Azure Blob Storage, and Google Cloud Storage connectors:
Checking this box reprocesses all documents in the source location on every workflow run.
Unchecking this box causes only new documents that are added to the source location, or existing documents that are updated in the source location, since the last workflow run to be processed on future runs. Previously processed documents are not processed again. However:
Click Continue.
If you want this workflow to run on a schedule, in the Repeat Run dropdown list, select one of the scheduling options, and fill in the scheduling settings. Otherwise, select Don’t repeat.
Click Complete.
Process the documents
Monitor the processing job
View the processed data
Go to your destination location to view the processed data.
